Digital Photography Terms
You control Time!

Do you stutter when someone asks you about your shutter? Read on to learn what your camera’s shutter does and why its speed and timing are so important.

Digital Photography Terms - Shutter

Digital Photography Terms: What is shutter? The shutter is the mechanism in a camera that opens and closes to allow light onto the camera’s digital sensor (or film).

The shutter is simply the window (or door) that is opened to let light into your camera and onto your camera’s sensor where it is recorded. The shutter is opened by pressing the shutter release button on the top of your camera.

Shutters are one of the few moving parts of your camera and are affected by wear-and-tear just like any other machine that moves. As your camera ages you can expect issues at some point with your shutter. All cameras and users are different, but you should be able to get 100,000 or more shutter releases on a camera (shutter release = picture taken).

Shutter Speed - the speed at which the shutter
opens and closes. That was easy.

The shutter, and more importantly how long the shutter is open, is a major determiner when choosing your exposure methods. Sports photographers require faster shutter speeds than landscape photographers because mountains just don't move that fast.

When buying a camera you want to pay attention to the camera’s shutter and particularly its fastest shutter speed. My Canon 60D’s shutter can open and close, at its fastest, at 1/8000th of a second. That’s pretty fast.

Another thing to consider is the burst rate of your camera. Burst rate indicates how many pictures your camera can take in rapid succession. This is another top feature pro sports photographers look for in their cameras. Burst rate also deals with how fast your camera can process images as they are piling into your storage card. So, burst rate is not all about how fast the shutter can open and close and open and close and open and close.

Digital Photography Terms | Shutter
Pin It

Above: By using a slower shutter speed, the movement of the dog is blurry (this is called motion blur). This photo was taken with a Canon D30 and a Sigma 20mm f/1.8. The shutter speed was .01s (1/100 of a second) a relatively fast shutter speed but not fast enough to freeze the dog's motion.

Fast Vs. Slow Shutter

Your shutter speed is used to allow light to hit the camera sensor. A faster shutter speed means less light on your camera’ sensor. A slower shutter speed means more light on your camera’s sensor.

An example of a fast shutter speed is 1/5000th of a second. An example of a slow shutter speed is 8 seconds.

Use your shutter speed in conjunction with your ISO setting and the f-stop setting on your lens to capture and control the amount of light you want to place on your camera’s sensor.

You cannot stay still for 8 seconds. Use a tripod when shooting using a lengthy shutter speed.
Pin It

Above: Camera - Canon 60D. Lens - Canon 200mm f/2.8L USM. Shutter Speed - 8 seconds. ISO - 125.  Aperture - f/3.5.  And a tripod! There's no way I could stay still for 8 seconds.

Shutter Rules

Since all rules are meant to be broken, I won't call these rules, instead I will call them guidelines.

Whenever you shoot below 1/60th of a second, consider using a tripod, placing your camera on something stable (like a table) or gathering up your inner Buddha guy to be more still than normal.

The reason for this guideline is that once you drop below 1/60th of a second shutter speed your own body movement will create camera shake that will result in a less than sharp picture.

Camera shake is caused by the photographer, motion blur is caused by the photographer's subject. Both result in blurry pictures. To avoid the blur use a faster shutter speed or consider a tripod or something to stabilize the camera.

Another shutter "rule" that will help you capture sharp images (and avoid camera shake) is to use a shutter speed equal to or greater than your lens' focal length. For example, if you are shooting with a 200mm focal length use a shutter speed of 1/200th or faster. A 400mm focal length requires a shutter speed of 1/400th of a second.

This is all thrown out the window if you have a tripod because the tripod will, ideally, eliminate camera shake. Although, a tripod is of no use in preventing motion blur.

Shutter Rules Side Note: You can use longer shutter speeds and still shoot hand held if you are using a wide focal length. In a very untechnical description, wide focal lengths (20mm, 15mm, 10mm and the like) absorb your body movement.

Have you ever seen video of a UFO and the camera is shaky and pretty much all over the place? That is due to the fact that as you zoom in you must have a faster shutter speed to prevent all of that commotion. But video and photo are different and it is not as simple as increasing shutter speed for video to prevent camera shake.

Stay calm to avoid camera shake. If your shutter speed is set too slow your movement (which in turn moves the camera) will give your picture a shaky look. This is called camera shake. Remember, only you can prevent camera shake.

Digital Photography Terms | Shutter
Pin It

 Above:  You can actually follow the movement that camera was making while the shutter was open by following the movement of the lines in the picture. Notice the red lines to the left of the ambulance. You can clearly see that the camera had a small vertical movement with a more lengthy horizontal one.  Photo taken with a Canon D30 and a Sigma 18-50mm f/2.8. Shutter speed: .06s (6/10 of a second).

The Quick and the Blurry

The quickness in which your shutter opens and closes will play two important parts in creating your final picture.

Your shutter speed determines if the action within your shot is blurry or sharp. If your subject is moving quickly use a fast shutter speed to stop the action. The faster the shutter speed, the more “still” your subject will be if it is moving.

If your subject is moving and you use a longer shutter speed, the resulting picture will give you a blurry subject (resulting in motion blur).

You shutter speed setting also has a direct affect on how much light is used in your exposure. Use your shutter speed in conjunction with your ISO and Aperture settings to get the exposure you desire. This is all covered in another article on photography basics.

Shutter Speed and Sports
Pin It

Above: Use a fast shutter speed to stop motion and prevent blurry images. This photo was taken with a Canon 60D and a Canon 200mm f/2.8L USM lens. The shutter speed was set at 1/5000th of a second. ISO: 200. f-stop: f/3.5.

Photography Tutorial | How To Work With Shutter

Thanks to Lynda.com for this video that gives a good overview of why it is important to always check your shutter speed when you are working in semi-auto mode.
